It is a highly efficient water treatment technology that integrates magnetic flocculation and coagulation sedimentation. By adding magnetic powder and flocculant to the water, the adsorption and weight-increasing effect of the magnetic powder is used to enhance the coagulation and sedimentation effect, thereby achieving rapid solid-liquid separation. It is widely used in sewage upgrading, reclaimed water reuse, and tap water purification.

Working principle:

Special magnetic powder is added to the coagulation system. The magnetic powder combines with flocculant and suspended solids in the water to form magnetic flocs. Because the density of magnetic flocs is much higher than that of ordinary flocs, they can settle quickly in the sedimentation tank, greatly shortening the sedimentation time. After settling, the magnetic flocs are transported to the magnetic separation equipment through the sludge return system to achieve efficient separation of magnetic powder and sludge. The magnetic powder can be recycled, while the sludge enters the subsequent dewatering stage.

Core components:

The complete magnetic coagulation treatment system mainly includes a reagent dosing unit (magnetic powder, flocculant, coagulant aid), a mixing and reaction unit, a magnetic flocculation sedimentation unit, a magnetic powder recovery unit, a sludge treatment unit, and an automatic control system. Each unit is integrated into a single design, requiring minimal space.

Technical Parameter Table:

Application areas:

Suitable for upgrading municipal wastewater treatment plants (removing total phosphorus and suspended solids), pretreatment of industrial wastewater (such as dyeing, electroplating, and chemical wastewater), surface water purification, black and odorous water body treatment, and pretreatment for reclaimed water reuse.
